BSW/BSF/Whitworth Thread Gauges

BSW / BSF / Whitworth threads are used where clearance between male & female threads is to be controlled.
This uses Imperial system of units.

Specification:

Basic Dimensions- BS 84-2007 & Gauging Practice: BS 919 Part II – 2007.

Manufacturing Range:

Thread Plug & Ring Gauges from Diameter 1/8 to 6″, TPI 40 to 2.5

Dia. Inch

BSW

BSF

BSB

Type of Thread Gauges used

1/8

40

–

26

Thread Plug Gauges.

Thread Ring Gauges.

Check Plug Gauges to Check New Rings.

Wear Check Plug Gauges to Check / Calibrate used Rings.

3/16

24

32

26



* 7/32

–

28

*



1/4

20

26

26



5/16

18

22

26



3/8

16

20

26



7/16

14

18

26



1/2

12

16

26



*9/16

12

16

26



5/8

11

14

26



*11/16

11

14

*



3/4

10

12

26



7/8

9

11

26



1

8

10

26



1.1/8

7

9

26



1.1/4

7

9

26



*1.3/8

–

8

26



.1/2

6

8

26



1.3/4

5

7

26



2

4.5

7

26



2.1/4

4

6

*



2.1/2

4

6

*



2.3/4

3.5

6

*



3

3.5

5

*



*3.1/4

3.25

5

*



3.1/2

3.25

4.5

*



*3.3/4

3

4.5

*



4

3

4.5

*



4.1/2

2.875

4

*



5

2.75

–

*



5.1/2

2.625

–

*



6

2.5

–

*
